Tube Mill Machine Line
0102030405
Square Round GI MS Pipe Manufacturing Machine
Introducing our latest tube manufacturing innovation - the MS tube machine. This state-of-the-art equipment is designed to meet the growing demand for mild steel pipes with the highest efficiency and precision. With advanced technology and strong structure, the equipment can process pipes of various diameters and thicknesses, and is a universal solution for various manufacturing requirements.
As a company mainly engaged in high-frequency welded pipe equipment of various specifications, we have used our expertise to develop MS pipe making machines. Our commitment to providing high quality and reliable equipment is reflected in the design and performance of this machine. It is equipped with cutting-edge features that ensure the production process, resulting in high-quality pipes that meet industry standards.
One of the main highlights of the MS pipe making machine is its ability to support customization. This means that manufacturers can tailor their production processes to their specific requirements, resulting in increased flexibility and productivity. In addition, our machines have perfect after-sales service, providing our customers with continuous support and maintenance guarantees, ensuring uninterrupted operation and peace of mind.
In summary, the MS pipe making machine represents a major advance in the field of pipe making machine equipment. Its cutting-edge technology, versatility and commitment to customer satisfaction make it an ideal choice for manufacturers looking for efficient and reliable solutions. With our dedication to innovation and quality, we are proud to offer this machine as a testament to our ongoing commitment to industry excellence."
Our Product
MIVI High-frequency Welding Pipe Making Machine Line
Item No. |
Outer diameter |
Wall thickness |
Production speed |
Driving motor |
HF welder power |
|---|---|---|---|---|---|
| MG-16 | 7mm-25mm | 0.3mm-1.0mm | 30-100m/min | 22kw*1set | 60kw |
| MG-25 | 8mm-32mm | 0.4mm-1.2mm | 30-100m/min | 45kw*1set | 60kw |
| MG-28 | 10mm-50.8mm | 0.5mm-1.8mm | 30-100m/min | 75kw*1set | 100kw |
Item No. |
Outer diameter |
Wall thickness |
Production speed |
Driving motor |
HF welder power |
|---|---|---|---|---|---|
| MG-32 | 13mm-50.8mm | 0.6mm-2.0mm | 30-100m/min | 90kw*1set | 100kw |
| MG-50 | 19mm-76mm | 0.7mm-2.75mm | 30-100m/min | 90kw*2set | 200kw |
| MG-60 | 25mm-80mm | 1.0mm-3.25mm | 30-80m/min | 90kw*2set | 200kw |
Item No. |
Outer diameter |
Wall thickness |
Production speed |
Driving motor |
HF welder power |
|---|---|---|---|---|---|
| MG-76 | 30mm-90mm | 1.0mm-4.0mm | 15-70m/min | 132kw*2set | 300kw |
| MG-127 | 32mm-127mm | 1.5mm-4.0mm | 20-70m/min | 160kw+200kw | 400kw |
| MG-165 | 50mm-165mm | 2.0mm-5.0mm | 30-50m/min | 200kw*2set | 500kw |
Item No. |
Outer diameter |
Wall thickness |
Production speed |
Driving motor |
HF welder power |
|---|---|---|---|---|---|
| MG-45 | 13mm-63.8mm | 0.6mm-2.0mm | 30-120m/min | 160kw*1set | 200kw |
| MG-140 | 32mm-140mm | 0.8mm-4.0mm | 30-70m/min | 320kw*1set | 300kw |
| MG-219 | 76mm-219mm | 2.0mm-8.0mm | 30-45m/min | 280kw*1set | 280kw |
Item No. |
Outer diameter |
Wall thickness |
Production speed |
Driving motor |
HF welder power |
|---|---|---|---|---|---|
| MG-254 | 89mm-254mm | 2.0mm-7.0mm | 30-60m/min | 400kw*1set | 500kw |
Our Advantages
1 Own CNC process center it can control quality of machine by ourself. Reduce invested cost for your project.
2 Rich experience engineer team and service team, with on line technology guidance and one to one service .
3 Supporting ONE STOP service, meet all requirement what you want ,Factory drawing can customized .
Our Factory
Yangzhou Mivi Machinery Manufacturing Co., Ltd. is a professional tube mill line manufacturer with over 20 years exporting experience.
Our main products: tube mill machines, cold rolling mills and relevant mechanical accessories.
We have exported to more than 20 countries and customzation service is avaliable for different requirements.
Now our factory have ISO9001, ISO14001certifications.
Welcome to inquiry us for more details. We will try our best to do win-win cooperation business.
Our Certificates
Our Exhibition
FAQ：
Q: What products do you make?
A: Our products are mainly various types of pipe making machines. We have a lot of experience in this field.
Q: What are the advantages of your machines?
A: We have first-class suppliers. Support customization, worry-free after-sales.
Q: Can you put the company name or logo on the product?
A: Yes. We can print your logo or company name on the product by stamping or coating it
Q: How many workers do you need to operate this machine?
A: If the worker knows how to operate the machine, one worker can operate two machines at the same time.
Q: How long does it take to replace the roller on the machine?
A: If a worker changes the roller once, it takes about 3 hours, but sometimes it depends on whether the worker has it
Familiar enough to decide.
Q: How many tons does the average machine produce per month?
A: Our machines depend on the model. In this case, one machine can produce 70 tons per month.
Q: How do we get after-sales service for the machine?
A: We will provide installation, operation, maintenance and other aspects of technical support, you can also arrange technical engineers to the site
Your company.
