Industrial Automation Welding Tube Mill Line

Products

Industrial Automation Welding Tube Mill Line

Industrial automatic welded pipe production line is designed for efficient production of welded pipe production line. Utilize advanced tube welding technology and automation technology to ensure high precision, speed and consistency in tube manufacturing. This line increases productivity, reduces labor costs and improves overall product quality.

  • Outer Diameter 7mm-254mm
  • Wall Thickness 0.3mm-7.0mm
  • Production Speed 30-120m/min
  • Warranty 1 year
  • Color Custom


description2

Product Details

Introduction of an industrial automatic welded pipe production line, an advanced solution designed to transform welded pipe manufacturing. This advanced system combines cutting-edge tube welding technology with sophisticated automated processes to ensure that every aspect of tube production is performed with unmatched precision and efficiency. Automated pipe lines are designed to meet the demands of modern manufacturing, providing an accurate experience from start to finish.
Industrial automatic welded pipe production lines stand out for their ability to significantly increase productivity and reduce labor costs. By automating key processes, the system minimizes the need for human intervention, enabling manufacturers to allocate labor more efficiently. The result is simplified operations that not only improve throughput, but also maintain a consistent level of quality across all products. With the welded pipe production line, the company's production capacity will be significantly increased, enabling it to easily meet market demand.
In addition, the commitment to quality is the top priority in the design of industrial automatic welded pipe production lines. The production line uses advanced technology to ensure that each welded pipe complies with strict industry standards, thereby improving the overall product quality. Manufacturers can be confident that their products are not only efficient but also reliable, positioning them well in a competitive market. In short, industrial automatic welded pipe production lines are the ideal solution for companies seeking to improve production processes, reduce costs and provide customers with high quality products.

Hot Rolling Mill (1)Hot Rolling Mill (1)

description2

Material Information

1

Applicable material

Hot rolled strip steel, galvanized strip steel

2

Material grade

Low carbon steel/low alloy steel≤350Mpa

3

Inner diameter of strip steel

Φ508mm

4

Outer diameter of strip steel

≤Φ2200mm

5

Weight of coil

35tons

description2

Finished Product Information

1 Outer diameter of pipe Φ219 ~Φ406mm
2 Thickness range of pipe 4 .0~ 12 .7mm
3 Length of pipe 4m--12m
4 Speed of production line 40m/ min

description2

Custom Rollers

machine production shows

description2

Tube Mill Making Machine

Model Outer diameter Pipe thickness Square tube size Square tube thickness Produce speed
MG-16 7mm-25mm 0.3mm-1.0mm 10mm*10mm-20mm*20mm 0.3mm-0.8mm 30m-100m/min
MG-25 8mm-32mm 0.4mm-1.2mm 10mm*10mm-25mm*25mm 0.4mm-1.0mm 30m-100m/min
MG-28 10mm-50.8mm 0.5mm-1.8mm 10mm*10mm-45mm*45mm 0.6mm-1.5mm 30m-100m/min
MG-32 13mm-50.8mm 0.6mm-2.0mm 10mm*10mm-40mm*40mm 0.6mm-1.5mm 30m-100m/min
MG-45 13mm~60mm 0.6mm-2.5mm 10mm*10mm~45mm*45mm 0.6mm~2.0mm 30m-100m/min
MG-50 19mm-76mm 0.7mm-2.75mm 15mm*15mm-60mm*60mm 0.6mm-2.0mm 30m-100m/min
MG-60 25mm-80mm 1.0mm-3.25mm 20mm*20mm-50mm*50mm 0.8mm-3.0mm 30m-80m/min
MG-76 30mm-90mm 1.0mm-4.0mm 50mm*50mm-130mm*130mm 1.5mm-4.0mm 15m-70m/min
MG-127 32mm-127mm 1.5mm-4.0mm 50mm*50mm-130mm*130mm 1.5mm-4.0mm 20m-70m/min
MG-140 32mm-140mm 0.8mm~4.0mm 25mm*25mm-110mm*110mm 0.8mm-3.5mm 30m-70m/min
MG-165 50mm-165mm 2.0mm-5.0mm 25mm*25mm-100mm*100mm 1.0mm-4.0mm 30m-50m/min
MG-172 89mm-172mm 1.0mm~5.0mm 70mm*70mm~130mm*130mm 1.0mm-4.0mm 30m-70m/min
MG-219 76.2mm-219.1mm 2.0mm~8.0mm 60mm*60mm~170mm*170mm 2.0mm-8.0mm 30m-45m/min
MG-254 89mm-254mm 2.0mm~7.0mm 70mm*70mm~200mm*200mm 2.0mm-6.0mm 30m-60m/min
For more customizations, please contact

description2

Company Introduction

At Mivi Machinery Company, we specialize in the manufacture of carbon steel pipe making machines. Our machines are designed to meet the unique needs of our clients, offering custom solutions to fit their specific requirements.

Our Factory

description2

Our Certificates

certificate

description2

Our Exhibition

Our Exhibition

description2

Pipe Making Machine FAQ Tube Mill
