Tube Mill Machine Line
0102030405
Factory Galvanized ERW MS Pipe Making Machine
Introducing our state-of-the-art carbon steel pipe making machine, a high-frequency pipe welding machine that sets the standard for precision and efficiency in the production of electric resistance welded (ERW) pipe. This specialized equipment is designed to meet the need for manufacturing high quality pipes with precise dimensions and smooth surface finish. With advanced technology and engineering excellence, our machines are key to producing top-notch industrial and commercial piping systems.
Our carbon steel pipe making machines are equipped with cutting-edge features that ensure pipe welding, making them an indispensable asset in any pipe manufacturing operation. The high-frequency welding technology used in this machine ensures the production of durable and reliable pipes that meet industry standards. Whether it's construction, infrastructure or a variety of industrial applications, our machines deliver the performance and precision required to manufacture quality pipes.
In addition to superior welding capabilities, our carbon steel pipe making machines are also capable of producing galvanized pipe, further extending their versatility and utility. This means that our machines are not only ideal for manufacturing standard carbon steel pipes, but can also meet the needs of producing corrosion-resistant and durable galvanized pipes for a variety of applications.
With our carbon steel pipe making machines, you can efficiently and cost-effectively produce ERW pipe to the highest quality and performance standards. Its advanced technology, precision engineering and versatility make it ideal for businesses looking to enhance their pipe manufacturing capabilities. Invest in our high frequency pipe welding machines to take your production processes to new heights of excellence and efficiency.
Our Product
MIVI High-frequency Welding Pipe Making Machine Line
Item No. |
Outer diameter |
Wall thickness |
Production speed |
Driving motor |
HF welder power |
|---|---|---|---|---|---|
| MG-16 | 7mm-25mm | 0.3mm-1.0mm | 30-100m/min | 22kw*1set | 60kw |
| MG-25 | 8mm-32mm | 0.4mm-1.2mm | 30-100m/min | 45kw*1set | 60kw |
| MG-28 | 10mm-50.8mm | 0.5mm-1.8mm | 30-100m/min | 75kw*1set | 100kw |
Item No. |
Outer diameter |
Wall thickness |
Production speed |
Driving motor |
HF welder power |
|---|---|---|---|---|---|
| MG-32 | 13mm-50.8mm | 0.6mm-2.0mm | 30-100m/min | 90kw*1set | 100kw |
| MG-50 | 19mm-76mm | 0.7mm-2.75mm | 30-100m/min | 90kw*2set | 200kw |
| MG-60 | 25mm-80mm | 1.0mm-3.25mm | 30-80m/min | 90kw*2set | 200kw |
Item No. |
Outer diameter |
Wall thickness |
Production speed |
Driving motor |
HF welder power |
|---|---|---|---|---|---|
| MG-76 | 30mm-90mm | 1.0mm-4.0mm | 15-70m/min | 132kw*2set | 300kw |
| MG-127 | 32mm-127mm | 1.5mm-4.0mm | 20-70m/min | 160kw+200kw | 400kw |
| MG-165 | 50mm-165mm | 2.0mm-5.0mm | 30-50m/min | 200kw*2set | 500kw |
Item No. |
Outer diameter |
Wall thickness |
Production speed |
Driving motor |
HF welder power |
|---|---|---|---|---|---|
| MG-45 | 13mm-63.8mm | 0.6mm-2.0mm | 30-120m/min | 160kw*1set | 200kw |
| MG-140 | 32mm-140mm | 0.8mm-4.0mm | 30-70m/min | 320kw*1set | 300kw |
| MG-219 | 76mm-219mm | 2.0mm-8.0mm | 30-45m/min | 280kw*1set | 280kw |
Item No. |
Outer diameter |
Wall thickness |
Production speed |
Driving motor |
HF welder power |
|---|---|---|---|---|---|
| MG-254 | 89mm-254mm | 2.0mm-7.0mm | 30-60m/min | 400kw*1set | 500kw |
Our Advantages
1 Own CNC process center it can control quality of machine by ourself. Reduce invested cost for your project.
2 Rich experience engineer team and service team, with on line technology guidance and one to one service .
3 Supporting ONE STOP service, meet all requirement what you want ,Factory drawing can customized .
Our Factory
Yangzhou Mivi Machinery Manufacturing Co., Ltd. is a professional tube mill line manufacturer with over 20 years exporting experience.
Our main products: tube mill machines, cold rolling mills and relevant mechanical accessories.
We have exported to more than 20 countries and customzation service is avaliable for different requirements.
Now our factory have ISO9001, ISO14001certifications.
Welcome to inquiry us for more details. We will try our best to do win-win cooperation business.
Our Certificates
Our Exhibition
FAQ：
Q: What products do you make?
A: Our products are mainly various types of pipe making machines. We have a lot of experience in this field.
Q: What are the advantages of your machines?
A: We have first-class suppliers. Support customization, worry-free after-sales.
Q: Can you put the company name or logo on the product?
A: Yes. We can print your logo or company name on the product by stamping or coating it
Q: How many workers do you need to operate this machine?
A: If the worker knows how to operate the machine, one worker can operate two machines at the same time.
Q: How long does it take to replace the roller on the machine?
A: If a worker changes the roller once, it takes about 3 hours, but sometimes it depends on whether the worker has it
Familiar enough to decide.
Q: How many tons does the average machine produce per month?
A: Our machines depend on the model. In this case, one machine can produce 70 tons per month.
Q: How do we get after-sales service for the machine?
A: We will provide installation, operation, maintenance and other aspects of technical support, you can also arrange technical engineers to the site
Your company.
