Tube Mill Machine Line
0102030405
Automatic Pipe Making Machine Tube Mill Line Manufacturing
The introduction of automatic pipe making machine pipe production line manufacturing, to solve the cutting-edge solution of efficient and accurate production of pipes. This state-of-the-art line is designed to meet the modern manufacturing needs of a variety of industries, providing high quality and consistent output. The system's integrated advanced technology ensures optimal performance, making it ideal for businesses looking to increase productivity and reduce production costs.
Pipe production line manufacturing is equipped with automated processes and advanced control systems to achieve seamless operation and reduce human intervention. This not only increases productivity, but also ensures precision and accuracy in the manufacturing process. The line is capable of efficiently producing pipes and is a reliable solution for businesses looking to streamline their manufacturing operations.
This innovative line is particularly suitable for the production of carbon steel tubes, providing a universal solution for companies in the steel and construction industries. The machine's advanced technology and rugged construction enable it to meet the requirements of heavy manufacturing, delivering consistently high quality results.
In addition to efficiency and precision, automatic pipe making machine pipe lines are manufactured to meet the highest industry standards for safety and reliability. Businesses can count on the durability and performance of the system, knowing that it can withstand the rigors of continuous operation while maintaining the highest levels of quality and safety.
In summary, automatic pipe making machine pipe line manufacturing is the most advanced solution for companies wishing to increase their pipe manufacturing capabilities. The production line has advanced technology, process automation and reliable performance, which has a competitive advantage in modern manufacturing industry. Whether producing carbon steel tubes or other types of tubes, companies can rely on the system to deliver consistently high-quality results while optimizing productivity and reducing production costs.
Our Product
MIVI High-frequency Welding Pipe Making Machine Line
Item No. |
Outer diameter |
Wall thickness |
Production speed |
Driving motor |
HF welder power |
|---|---|---|---|---|---|
| MG-16 | 7mm-25mm | 0.3mm-1.0mm | 30-100m/min | 22kw*1set | 60kw |
| MG-25 | 8mm-32mm | 0.4mm-1.2mm | 30-100m/min | 45kw*1set | 60kw |
| MG-28 | 10mm-50.8mm | 0.5mm-1.8mm | 30-100m/min | 75kw*1set | 100kw |
Item No. |
Outer diameter |
Wall thickness |
Production speed |
Driving motor |
HF welder power |
|---|---|---|---|---|---|
| MG-32 | 13mm-50.8mm | 0.6mm-2.0mm | 30-100m/min | 90kw*1set | 100kw |
| MG-50 | 19mm-76mm | 0.7mm-2.75mm | 30-100m/min | 90kw*2set | 200kw |
| MG-60 | 25mm-80mm | 1.0mm-3.25mm | 30-80m/min | 90kw*2set | 200kw |
Item No. |
Outer diameter |
Wall thickness |
Production speed |
Driving motor |
HF welder power |
|---|---|---|---|---|---|
| MG-76 | 30mm-90mm | 1.0mm-4.0mm | 15-70m/min | 132kw*2set | 300kw |
| MG-127 | 32mm-127mm | 1.5mm-4.0mm | 20-70m/min | 160kw+200kw | 400kw |
| MG-165 | 50mm-165mm | 2.0mm-5.0mm | 30-50m/min | 200kw*2set | 500kw |
Item No. |
Outer diameter |
Wall thickness |
Production speed |
Driving motor |
HF welder power |
|---|---|---|---|---|---|
| MG-45 | 13mm-63.8mm | 0.6mm-2.0mm | 30-120m/min | 160kw*1set | 200kw |
| MG-140 | 32mm-140mm | 0.8mm-4.0mm | 30-70m/min | 320kw*1set | 300kw |
| MG-219 | 76mm-219mm | 2.0mm-8.0mm | 30-45m/min | 280kw*1set | 280kw |
Item No. |
Outer diameter |
Wall thickness |
Production speed |
Driving motor |
HF welder power |
|---|---|---|---|---|---|
| MG-254 | 89mm-254mm | 2.0mm-7.0mm | 30-60m/min | 400kw*1set | 500kw |
Our Advantages
1 Own CNC process center it can control quality of machine by ourself. Reduce invested cost for your project.
2 Rich experience engineer team and service team, with on line technology guidance and one to one service .
3 Supporting ONE STOP service, meet all requirement what you want ,Factory drawing can customized .
Our Factory
Yangzhou Mivi Machinery Manufacturing Co., Ltd. is a professional tube mill line manufacturer with over 20 years exporting experience.
Our main products: tube mill machines, cold rolling mills and relevant mechanical accessories.
We have exported to more than 20 countries and customzation service is avaliable for different requirements.
Now our factory have ISO9001, ISO14001certifications.
Welcome to inquiry us for more details. We will try our best to do win-win cooperation business.
Our Certificates
Our Exhibition
FAQ：
Q: What products do you make?
A: Our products are mainly various types of pipe making machines. We have a lot of experience in this field.
Q: What are the advantages of your machines?
A: We have first-class suppliers. Support customization, worry-free after-sales.
Q: Can you put the company name or logo on the product?
A: Yes. We can print your logo or company name on the product by stamping or coating it
Q: How many workers do you need to operate this machine?
A: If the worker knows how to operate the machine, one worker can operate two machines at the same time.
Q: How long does it take to replace the roller on the machine?
A: If a worker changes the roller once, it takes about 3 hours, but sometimes it depends on whether the worker has it
Familiar enough to decide.
Q: How many tons does the average machine produce per month?
A: Our machines depend on the model. In this case, one machine can produce 70 tons per month.
Q: How do we get after-sales service for the machine?
A: We will provide installation, operation, maintenance and other aspects of technical support, you can also arrange technical engineers to the site
Your company.
